LABOKLAV Series Autoclave

LABOKLAV Steam Sterilizers – Precision and Performance for Every Laboratory

The LABOKLAV range offers flexible and powerful solutions for laboratories, research institutions, universities, and industrial quality control departments. With chamber volumes ranging from 25 to 195 liters, LABOKLAV autoclaves adapt to a wide array of sterilization tasks, from basic laboratory applications to the most demanding and regulated environments.

Engineered for versatility, these autoclaves are available in benchtop or vertical models and include various configurations such as:

• Basic (B): Standard sterilization
• M: With rapid air cooling
• V: With vacuum system for better drying and air removal
• MV/MSV/MSLV: Combining cooling, pressure support, and vacuum for optimal performance and shortest cycle times

LABOKLAV units support the sterilization of:

• Liquids in open or loosely sealed containers
• Solid instruments and tools, including pipette tips and textiles
• Contaminated waste materials, including for destructive sterilization at 134°C

All LABOKLAV models are equipped with intuitive user interfaces, motorized safety doors, and a memory chip capable of storing up to 200 sterilization cycles. An optional matrix printer and USB/SD data export ensure reliable documentation for regulatory compliance. Some models include touch screens and integrated web servers for remote monitoring and diagnostics.

The LABOKLAV ECO series is perfect for cost-effective laboratory setups, while high-capacity units like the LABOKLAV 135 and Wastewater 135 specialize in sterilizing large volumes of liquids safely and efficiently.

LABOKLAV 25

• Chamber volume: 25 litres
• Chamber dimensions (Ø x D): 265 x 465 mm
• Overall dimensions (W x H x D): 440 x 540 x 660 mm
• Weight: 65 kg
• Maximum permissible pressure (PS): 2.8 bar
• Maximum permissible temperature (TS): 143°C
• Steam generator heat output: 2 kW
• Electrical connection: 230V –, 50 Hz, 16 A, alternating current
• Sterilisation temperature: adjustable from 98 to 135°C

---
LABOKLAV ECO 80

• Chamber volume: 80 litres
• Chamber dimensions (Ø x D): 410 x 610 mm
• Overall dimensions of vertical autoclave (W x H x D): 740 x 915 x 600 mm
• Weight: 155 kg
• Maximum permissible pressure (PS): 2.8 bar
• Max. permissible temperature (TS): 143°C
• Heat output: 3 kW
• Electrical connection: 230V –, 50 Hz, 16 A, alternating current
• Sterilisation temperature: adjustable from 98 to 135°C

---
LABOKLAV ECO 135

• Chamber volume: 135 litres
• Chamber dimensions (Ø x D): 500 x 660 mm
• Overall dimensions of vertical autoclave (W x H x D): 840 x 965 x 700 mm
• Weight: 195 kg
• Maximum permissible pressure (PS): 2.8 bar
• Max. permissible temperature (TS): 143°C
• Heat output: 6 kW
• Electrical connection: 3N 400V –, 50 Hz, 16 A
• Sterilisation temperature: adjustable from 98 to 135°C

---
LABOKLAV 55

• Chamber volume: 55 litres
• Chamber dimensions (Ø x D): 410 x 460 mm
• Overall dimensions of vertical autoclave (W x H x D): 740 x 765 x 600 mm
• Weight: 115 kg
• Maximum permissible pressure (PS): 2.8 bar
• Max. permissible temperature (TS): 143°C
• Steam generator heat output: 3-6 kW, selectable
• Electrical connection: 3N 400V –, 50 Hz, 16 A
• Sterilisation temperature: adjustable from 98 to 135°C

---
LABOKLAV 80

• Chamber volume: 80 litres
• Chamber dimensions (Ø x D): 410 x 610 mm
• Overall dimensions of vertical autoclave (W x H x D): 740 x 915 x 600 mm
• Weight: 155 kg
• Maximum permissible pressure (PS): 2.8 bar
• Max. permissible temperature (TS): 143°C
• Steam generator thermal power: 3-10 kW, selectable
• Electrical connection: 3N 400V –, 50 Hz, 16 A
• Sterilisation temperature: adjustable from 98 to 135°C

---
LABOKLAV 100

• Chamber volume: 100 litres
• Chamber dimensions (Ø x D): 410 x 760 mm
• Overall dimensions of vertical autoclave (W x H x D): 740 x 1065 x 600 mm
• Weight: 185 kg
• Maximum permissible pressure (PS): 2.8 bar
• Max. permissible temperature (TS): 143°C
• Thermal power of steam generator: 6-10 kW, selectable
• Electrical connection: 3N 400V –, 50 Hz, 16 A
• Sterilisation temperature: adjustable from 98 to 135°C

---
LABOKLAV 135

• Chamber volume: 135 litres
• Chamber dimensions (Ø x D): 500 x 660 mm
• Overall dimensions of vertical autoclave (W x H x D): 840 x 965 x 700 mm
• Weight: 195 kg
• Maximum permissible pressure (PS): 2.8 bar
• Max. permissible temperature (TS): 143°C
• Thermal power of steam generator: 6-10 kW, selectable
• Electrical connection: 3N 400V –, 50 Hz, 16 A
• Sterilisation temperature: adjustable from 98 to 135°C

---
LABOKLAV 160

• Chamber volume: 160 litres
• Chamber dimensions (Ø x D): 500 x 760 mm
• Overall dimensions of vertical autoclave (W x H x D): 840 x 1065 x 700 mm
• Weight: 210 kg
• Maximum permissible pressure (PS): 2.8 bar
• Max. permissible temperature (TS): 143°C
• Thermal power of steam generator: 6-10 kW, selectable
• Electrical connection: 3N 400V –, 50 Hz, 16 A
• Sterilisation temperature: adjustable from 98 to 135°C

---
LABOKLAV 195

• Chamber volume: 195 litres
• Chamber dimensions (Ø x D): 500 x 990 mm
• Overall dimensions of vertical autoclave (W x H x D): 840 x 1215 x 700 mm
• Weight: 245 kg
• Maximum permissible pressure (PS): 2.8 bar
• Max. permissible temperature (TS): 143°C
• Thermal power of steam generator: 10 kW
• Electrical connection: 3N 400V –, 50 Hz, 16 A
• Sterilisation temperature: adjustable from 98 to 135°C
