OptiForce OFT200 interferometer

The OptiForce OFT200 from IonOptix is a stand-alone fibre optic interferometer designed for precise, non-contact displacement measurements. Using a single-mode fibre, it offers extremely low displacement noise levels, down to 2 pm/√Hz, over a travel range of several hundred micrometres. Ideal for research applications, it provides a real-time linear displacement signal with 16-bit resolution and a frequency of up to 20 kHz.



Description

OptiForce OFT200: A Precision Interferometer for Research

The OptiForce OFT200 from IonOptix is a high-performance device designed for high-precision displacement measurements. Using fibre optic interferometry technology, this device enables contactless measurements, making it particularly suitable for sensitive or extreme environments. Thanks to a single-mode optical fibre, the OptiForce can achieve extremely low displacement noise levels of up to 2 pm/√Hz over a travel range of several hundred micrometres. This exceptional performance is made possible by continuous, high-speed real-time demodulation performed by an integrated FPGA.

The OptiForce is capable of providing a linear displacement signal in the form of an analogue voltage, with a resolution of 16 bits and a frequency of up to 20 kHz. This signal is automatically calibrated by the system, ensuring optimum accuracy and reliability. The device is equipped with a tunable laser, which allows the wavelength to be adjusted to match the quadrature point, ensuring maximum sensitivity and linear response.

The OptiForce OFT 200 is particularly suitable for research applications requiring precise, non-contact displacement measurements. It can be used in a variety of environments, including high temperatures, liquids, or intense electric and magnetic fields. The device also features an intuitive user interface, allowing for easy operation without the need for advanced technical skills.

The OptiForce OFT200 from IonOptix is a high-precision displacement measurement tool, ideal for research applications. With its exceptional performance, ease of use and versatility, it is the solution of choice for scientists and engineers seeking to perform accurate and reliable displacement measurements.

Features

  • Precise Displacement Measurement: Ability to measure displacement with extreme accuracy.
  • Contactless Operation: Ideal for sensitive or extreme environments.
  • Real-Time Demodulation: Ensures optimal linearity and accuracy.
  • Tunable Laser: Allows the wavelength to be adjusted for maximum sensitivity.
  • Intuitive User Interface: Easy to use without specific technical skills.
  • Automatic calibration: Guarantees optimum accuracy and reliability.
  • Versatility: Suitable for various environments, including high temperatures and intense electric and magnetic fields.
  • Connectivity: Enables easy integration with other measurement equipment.

Technical Details

  • Technology: Fibre optic interferometry
  • Optical Fibre: Single-mode
  • Displacement Noise Level: Up to 2 pm/√Hz
  • Measurement Range: Several hundred micrometres
  • Demodulation: Real-time, continuous, high-speed via FPGA
  • Output Signal: Analogue voltage, 16-bit resolution
  • Output Frequency: Up to 20 kHz
  • Laser: Tunable, Class 1M
  • Calibration: Automatic
  • User interface: LCD and navigation buttons
  • Connectivity: USB, BNC, 1 MHz photodetector output
  • Power supply: 220V/110V

Compatible Accessories

  • Force Sensors: Various types of sensors tailored to specific user requirements.
  • Mounting Bracket: For stable and accurate installation of the device.
  • Control Software: For managing and analysing measurement data.
