Zoll RESQPUMP ACD-CPR Chest Compressor: Advanced Assistance for Cardiac Resuscitation.

The Zoll RESQPUMP ACD-CPR chest compressor is a crucial innovation in the field of cardiopulmonary resuscitation (CPR). Designed for critical emergency situations, this device enables rescuers to perform CPR with an active compression and decompression (ACD-CPR) approach, which differs from standard CPR. During ACD-CPR, chest expansion (decompression) is actively performed after each compression, providing more efficient blood circulation compared to standard CPR.

The design of the RESQPUMP allows the operator to use the same body position and compression technique as in standard CPR. Active chest decompression is achieved when the rescuer maintains a firm grip on the RESQPUMP, leans at the waist, and lifts their own weight upward after each compression. The suction cup adheres to the chest and transfers the lifting force to the mid-chest. The compression force is transferred to the chest in the same way as in standard CPR, through the device's piston.

The handle of the RESQPUMP integrates a battery-powered metronome, which guides the rescuer on the appropriate rate of compression and decompression. The metronome emits signals in two tones of equal duration, a low tone and a high tone, to guide the rescuer in compression and decompression at the appropriate rate and for an equal duration (50% duty cycle).

The Zoll RESQPUMP ACD-CPR Chest Compressor represents a significant advancement in CPR techniques, improving the efficiency of chest compressions and thereby contributing to increased chances of survival in medical emergency situations.

• Dimensions:
• Diameter of suction cup: 13.5 cm
• Height: 17.0 cm
• Weight: 0.58 kg

• Metronome Function:
• Signal tones: 768 Hz (low) and 3070 Hz (high)
• Sound level: ≥65 dB at a distance of 0.5 m from the sound source
• Frequency: 80/min

• Materials:
• Suction cup and cushion: Silicone
• Handle and support ring: Polyamide (nylon), reinforced with fiberglass
• Connecting rod: Acetal polyoxymethylene
• Support ring: Thermoplastic polyester elastomer
• Metal parts: Stainless steel and brass
• Battery: 3.6 V primary lithium-thionyl chloride
